SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material

Short Boot sc patch cord

OFNR OFNP Fiber Optic Patch Cord

OFNR OFNP Material sc patch cord

Place of Origin:

CHINA

Brand Name:

JFOPT

Certification:

Product: CE/UL/ROHS/REACH, Company: ISO9001/ISO14001

Model Number:

SC Short Boot/BentBoot

Contact Us

Request A Quote
Product Details
Fiber Count:
Simplex Or Duplex
Fiber Type:
Single Mode G652D/G657A1/G657A2/G655, Multimode OM1/2/3/4/5
Cable Outer Diameter:
1.6-3.0mm
Boot Type:
12.5mm Short Boot, 13.5mm Short Boot, 45° Boot, 90° Boot
Flame Retardant Rating:
OFN/OFNR/OFNP
Insertion Loss:
≤0.3dB
Return Loss:
MM≥25dB, SM/UPC≥50dB, SM/APC≥60dB(Standard)
Repeatability:
LC DX
Payment & Shipping Terms
Minimum Order Quantity
1pc
Price
Quoted based on product length, model, and loss parameters
Delivery Time
1-5 days
Supply Ability
T/T / Paypal / Trade Assurance Order via Alibaba
RELATED PRODUCTS
Contact Us
86-755-83570641
Contact Now
Product Description

SC Fiber Optic Patch Cord With Short Tail / Bent Tail OFNR / OFNP Material



JFOPT has over 20 years of experience in the production of fiber optic patch cords. Our products comply with industry standards such as TIA 604 (FOCIS), IEC 61754, and YD/T. In addition to standard-sized and shaped fiber connectors, we also offer functional connectors such as short boots and bent boots, suitable for installations with limited space and high density. We provide fiber cables with outer diameters of 1.6/1.8/2.0/3.0mm and standard fibers of OS2/OM1/OM2/OM3/OM4/OM5. JFOPT maintains sufficient inventory to quickly meet customized demands and ensures safe and high-quality delivery through a comprehensive production and quality inspection process.



♦ Features

① Short boots and bent boots significantly reduce the connector size, suitable for high-density installations in small spaces

②Famous brand fibers are used to ensure link reliability

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 0

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 1

③ High-quality ceramic ferrules with low insertion loss reduce signal loss

④ 100% factory termination and testing ensure transmission performance

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 2

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 3

⑤Safe and aesthetically pleasing packaging, with the option for customized packaging for bulk orders

-

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 4

-



Applications

1.Fiber access networks
2.Fiber data transmission
3.Fiber communication systems, cable TV networks, telecommunication networks
4.Local area networks (LANs), wide area networks (WANs), FTTx



♦ Technical Parameters

Connector Characteristics

Connector Type

SC

PolisingType

Single-mode: UPC/APC; Multimode: UPC

Ferrule Material

A-grade zirconia ceramic ferrule

Matched Cable Outer Diameter

0.9mm/2.0mm/3.0mm/4.0mm

Connector Housing Color

Blue/Green/Beige/Aqua/Violet

Insertion Loss

≤0.3dB/≤0.2dB/≤0.15dB

Return Loss

Single-mode: UPC≥50dB; APC≥60dB; Multimode: ≥25dB

Repeatability

≤0.2dB

Interchangeability

≤0.2dB

Cable Characteristics

Fiber Type

OS2/OM1/OM2/OM3/OM4/OM5

Fiber Count

Single-core/Dual-core

Outer Diameter

1.6-3.0mm

Jacket Material

PVC/LSZH or Customized

Cable Color

Yellow/Orange/Aqua/Violet/Lime Green/Customized

Fire Rating

Optional OFN/OFNR/OFNP

Temperature Characteristics

Operating Temperature

-20~70℃

Storage Temperature

-40~80℃



♦ 3D Geometric Parameters (Optional)

Items

UPC

APC

SC/FC/ST

LC

SC/FC

LC

SM

MM

SM

MM

SM

SM

Radius of curvature (mm)

10-25

7-25

5-12

Apex offset (μm)

≤50

≤30

Fiber Depressed (nm)

±100

Angle deviation (°)

0

8±0.3

Bond angle deviation (°)

0

±0.5

Fiber diameter (μm)

123-135



♦ Options of Simplex Patch Cord

Cable Diameter

Boot Type


Drawing

2.0mm

Short Boot1

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 5

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 6

3.0mm

Short Boot1

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 7

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 8

2.0/3.0mm

45°Boot

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 9

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 10

2.0/3.0mm

90°Boot

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 11

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 12



♦ Options of Duplex Patch Cord

Cable Diameter

Boot Type


Drawing

2.0mm

Short Boot1

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 13

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 14

3.0mm

Short Boot1

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 15

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 16

2.0/3.0mm

45°Boot

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 17

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 18

2.0/3.0mm

90°Boot

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 19

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 20



♦ Connector Housing Color Options

SC Connector

Singlemode

Blue

Green

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 21

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 22

Multimode

Beige

Aqua

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 23

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 24

Heather Violet

-

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 25

-





♦ Duplex Polarity Selection

TYPE A-B(Straight)

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 26

TYPE A-A(Crossing)

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 27



♦ Product Packaging

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 28

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 29

Thickened ziplock bag

Thickened carton



Factory Strength

Specialization:


With a focus on fiber optic patch cord production for over 20 years, JFOPT has professional manufacturing techniques to produce high-quality and high-performance fiber optic patch cords.

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 30

Manufacturing Capacity:


JFOPT has 5 production lines and equipment that enable fast and efficient production of a large quantity of fiber optic patch cords to meet customer demands.

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 31

Quality Control:


JFOPT implements strict quality control measures, including professional quality testing and monitoring at every stage from raw material procurement to the production process, as well as insertion loss testing/end face testing to ensure product quality.

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 32

Standard Setting:


JFOPT can establish and strictly follow fiber optic patch cord production standards according to customer requirements to ensure product consistency and performance stability.

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 33

Technological Innovation:


JFOPT emphasizes technological innovation and has a professional research and development team continuously developing more advanced and higher-performing fiber optic patch cords.

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 34

Service and Technical Support:


JFOPT provides comprehensive pre-sales and after-sales services, including technical consultations, product recommendations, and after-sales repairs, to meet customer needs and ensure customer satisfaction.

SC Fiber Optic Patch Cord With Short Boot / Bent Boot OFNR OFNP Material 35



♦ Frequent Q&A

1.When customizing standard fiber jumpers, you need to pay attention to the following issues?

Fiber jumper length/Cable material/Fiber type and core count/Duplex polarity/Color/Labeling and other customization requirements.


2.How do we ensure the stability of our standard fiber jumpers?
JFOPT's standard fiber jumpers undergo 100% insertion loss testing and end-face inspection. Multiple inspections are performed to ensure stable quality.



3.What other advantageous products do we offer besides SC jumpers?
In addition to SC jumpers, we also produce FC/ST/LC and other standard model jumpers, connector adapter jumpers in various models, MPO adapters for standard connectors (such as LC), as well as outdoor waterproof fiber cables and jumpers. We also provide various non-standard and special model fiber connectors.



4.What is our delivery lead time?
For standard products, our delivery lead time can be controlled within 2 working days, ensuring prompt shipment for you.
