3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module

3 Layer Sliding Tray MPO Patch Panel

MPO 12 Core Cassette Module

MPO Patch Panel 144 Cores

Place of Origin:

CHINA

Brand Name:

JFOPT

Certification:

Product : CE / UL / ROHS / REACH , Company : ISO9001 / ISO14001

Model Number:

144 Cores 1U 19 inch MPO-LC 12F Cassettes MPO Patch Panel 3 layer sliding

Contact Us

Request A Quote
Product Details
Capacity:
144 Fibers
Structure:
3-layer Sliding Tray
Height:
1U
Opening Method:
Drawer Type With Sliding Rail
Cassette Number:
12
Interface Type:
MPO-LC
Color:
Black / Customized
Material:
Metal
Payment & Shipping Terms
Minimum Order Quantity
1pc
Price
Negotiable
Delivery Time
1-3 Days
Payment Terms
T/T /Paypal /Trade Assurance Order via Alibaba
Supply Ability
300 Units per day
RELATED PRODUCTS
Contact Us
86-755-83570641
Contact Now
Product Description

MPO Patch Panel 3 - Layer Sliding Tray 144 Cores 19 Inches 12 MPO Cassette MPO / PC - LC / UPC 12 - Core Cassette Module



JFOPP-MPO10-B-001 is an MPO patch panel that features an ultra-thin design while accommodating 12 MPO cassette modules within 1U space, supporting capacity of 144 fibers. The MPO cassette module allows for quick installation and wiring, and all three layers of rails can be fully extended, facilitating the insertion of MPO backbone jumpers and replacement of module boxes. The patch panel is manufactured by precision sheet metal equipment, employing high-quality cold-rolled steel plate materials and electrostatic spray surface treatment process to ensure excellent pressure resistance and impact resistance performance. The MPO distribution box is primarily used for fiber distribution and patching between pre-terminated backbone cables.



♦ Product Features

① Standard 1U 19-inch rack-mounted design

② Modular design to improve wiring efficiency

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 0

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 1

③Three-section rail for convenient and fast connections

④ Ball-bearing rail for smooth sliding

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 2

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 3

⑤ Adjustable mounting ears for compatibility with different installation environments

-

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 4

-



♦ Applications

1.Data centers
2.High-density fiber cabling systems
3.Backbone networks
4.FTTZ, FTTB cabling systems



♦ Cassette Dimension



3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 5

Dimension of Patch Panel

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 6

Accessory

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 7

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 8

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 9

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 10

Velcro

(12*100mm)*30pcs

cable ties

(3*100mm)*20pcs

Screw and nut

*4sets

Label

(80*20mm)*30pcs



♦ Product Packaging

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 11

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 12

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 13

Patch panel each corner protected by foam tape and wrapped with bubble tape

Inner carton box

Multiple inner boxes are packed into the outer box and sealed
Outer carton box has corner protector



 Factory Strength

Expertise:


JFOPT has over 10 years focused on the production of fiber optic patch panels, equipped with professional technology and equipment.

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 14

Manufacturing Capacity:


JFOPT utilizes precise laser cutting equipment, metal stamping equipment and CNC bending equipment for manufacturing.

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 15

Quality Control:


JFOPT implements strict quality control measures, including professional quality inspections at every stage, from sheet metal material to stamping, bending, and coating processes.

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 16

Standardization:


JFOPT can customize and strictly adhere to production standards for patch panels based on customer requirements, ensuring product consistency and performance stability.

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 17

Technological innovation:


JFOPT emphasizes technological innovation and has a professional team dedicated to the research and development of fiber optic patch panels, continuously developing more advanced and user-friendly products.

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 18

Service support:


JFOPT provides comprehensive pre-sales and after-sales services, including technical consultation, product recommendations, and after-sales maintenance, to meet customer needs and ensure customer satisfaction.

3 Layer Sliding Tray MPO Patch Panel 144 Cores 19 Inches 12 Cassette MPO/PC-LC/UPC 12 Core Cassette Module 19



♦ Frequent Q&A

1.What factors should be considered when purchasing fiber distribution box?
First, it should meet the requirements of the wiring construction and pay attention to the thickness of the sheet metal and structural strength to ensure a visually appealing and undamaged product. Usually, you can contact us for customized production based on your samples or technical drawings, or you can inform us of your requirements for us to design for you.



2.Can our fiber distribution box be compatible with MPO cassette modules from other manufacturers?
Compatibility depends on having the same installation dimensions. If the dimensions are not the same, they cannot be used together.



3.Can our fiber distribution box be matched with jumper cables?
We can provide jumper and pigtail according to your different needs to meet various wiring requirements.



4.What is our delivery lead time?
For standard products, it is within 2 working days, and for customized products, it is within 15 working days.
