MTP Multimode Fiber OM4 Single Row 8 Channels Low Loss Loopback
MTP Fiber Loopback is a passive device used to test the transmission capability and receiver sensitivity of network equipment. It is typically pluged into MTP/MPO adapters to form a loop in the transmitting and receiving channels, allowing the detection of potential anomalies in the network link. JFOPT's MTP Multimode Fiber OM4 Single Row 8-Channel Low Loss Loopback utilizes USCONEC components and ferrules. The unique key design of the 16-fiber MTP loopback differentiates it clearly from 12-fiber or 24-fiber MTP connectors, preventing misconnections. The back shell of the MTP loopback comes with a pulling ring for convenient installing and removal, even in tight distribution panels. All JFOPT loopbacks use bend-resistant single-mode or multimode fibers to ensure normal loss and meet miniaturization requirements.
♦ Product Features
|
① Complete set of original USCONEC components |
② High-quality, low-loss MTP multi-core ferrules |
||||
|
|
|
||||
|
③Adopt high-quality bend insensitive fibers to ensure stable transmission |
④ Good compatibility and high repeatability |
||||
|
|
|
||||
|
⑤ REACH and ROHS environmental certification |
- |
||||
|
|
- |
||||
♦ Applications
1.Optical system debugging
2.Fiber fault troubleshooting
3.High-density data centers
♦ MTP Connector Parameters
|
Connector Type |
Insertion Loss |
Return Loss |
|||
|
Typical |
Maximum |
||||
|
MTP Connector |
SM Standard |
0.25dB |
0.5dB |
APC≥60dB |
|
|
SM Low Loss |
0.12dB |
0.25dB |
|||
|
MM Standard |
0.2dB |
0.45dB |
PC≥25dB |
||
|
MM Low Loss |
0.12dB |
0.25dB |
|||
|
Male / Female |
Male : with Pin , Female : without Pin |
||||
♦ 3D Geometric Parameters
|
Items |
Max |
Min |
||
|
Radius of curvature (mm) |
X |
2000 |
-10000 |
|
|
Y |
- |
5 |
||
|
Angle (°) |
X |
0.15 |
-0.15 |
|
|
Y(APC) |
8.2 |
7.8 |
||
|
Y(PC) |
0.2 |
-0.2 |
||
|
Radius of curvature of optical core (mm) |
- |
1 |
||
|
Fiber height (nm) |
3500 |
1000 |
||
|
Height difference of adjacent fiber (nm) |
500 |
N/A |
||
|
Maximum negative coplanar (nm) |
300 |
N/A |
||
♦ Ferrule Specifications
|
Fiber Mode |
Performance |
Fiber count |
||
|
SM |
Standard SM |
4 channels (12-core ferrule) |
||
|
6 channels (12-core ferrule) |
||||
|
8 channels (16-core ferrule) |
||||
|
12 channels (24-core ferrule) |
||||
|
SM MT |
4 channels (12-core ferrule) |
|||
|
6 channels (12-core ferrule) |
||||
|
12 channels (24-core ferrule) |
||||
|
MM |
Standard SM |
4 channels (12-core ferrule) |
||
|
6 channels (12-core ferrule) |
||||
|
8 channels (16-core ferrule) |
||||
|
12 channels (24-core ferrule) |
||||
|
MM MT |
4 channels (12-core ferrule) |
|||
|
6 channels (12-core ferrule) |
||||
|
8 channels (16-core ferrule) |
||||
|
12 channels (24-core ferrule) |
||||
♦ Connector Color Selection
|
MTP connector |
||||
|
SM |
Green |
Yellow |
||
|
Reference Color: PANTONE 346C |
Reference Color: PANTONE 106C |
|||
|
|
|
|||
|
MM |
Beige |
Black |
||
|
Reference Color: PANTONE 7534U |
Reference Color: PANTONE Black 6C |
|||
|
|
|
|||
|
Aqua |
Heather Violet |
|||
|
Reference Color: PANTONE 310C |
Reference Color: PANTONE 1905C |
|||
|
|
|
|||
|
Munsell Violet |
Magenta |
|||
|
Reference Color: PANTONE 2587C |
Reference Color: PANTONE 208C |
|||
|
|
|
|||
|
Lime Green |
- |
|||
|
Reference Color: PANTONE 375C |
||||
|
|
||||
♦ Polarity Selection
|
12F Patch Cord |
||||
|
|
||||
|
24F Patch Cord |
||||
|
|
♦ Product Packaging
|
|
|
|
Thickened anti-static bag |
Reinforced packaging |
♦ Factory Strength
|
Specialization: JFOPT has been focusing on the production of MPO/MTP jumpers for over 10 years, with professional expertise and a complete set of top-notch brand equipment (SUMIX/JRG/OPTOTEST), enabling the production of high-quality, high-performance MPO/MTP jumpers. |
|
||||
|
Manufacturing capacity: JFOPT has 5 MPO production lines, capable of rapidly and efficiently producing large quantities of MPO/MTP jumpers to meet customer demands. |
|
||||
|
Quality Control: JFOPT implements strict quality control, including professional quality inspections and monitoring at every stage, from raw material to the production. 100% 3D interferometer testing/insertion loss testing/ferrule endface inspection ensures product quality. |
|
||||
|
Standardization: JFOPT can develop and strictly adhere to MPO jumper production standards according to customer requirements, ensuring consistency and performance stability of the products. |
|
||||
|
Technological innovation: JFOPT emphasizes technological innovation and has a professional R&D team dedicated to continuously developing advanced and high-performance MPO/MTP jumpers. |
|
||||
|
Service and Technical Support: JFOPT provides comprehensive pre-sales and after-sales services, including technical consultation, product recommendations, and post-sales repairs, to meet customer needs and ensure customer satisfaction. |
|
||||
♦ Frequent Q&A
1.What should be considered when customizing an MTP loopback adapter?
Fiber type and count / Connector gender / Wire sequence / Insertion loss standard / Color / Labeling and other customization requirements.
2.How do we ensure the stability of our MTP loopback adapter parameters?
JFOPT's MTP jumpers undergo 100% 3D interference testing and 100% insertion loss testing to ensure parameter stability.
3.What is our delivery time?
We can produce over 30,000 MTP connectors per month, ensuring prompt delivery for your orders.
