16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional

16 Core TTH Fiber Cable Box

Fiber Cable Box Midspan Gland Cover

FTTH Distribution Box 2 In 16 Out

Place of Origin:

CHINA

Brand Name:

JFOPT

Certification:

Product: CE/UL/ROHS/REACH Company: ISO9001/ISO14001

Model Number:

JFFDB-216-16B-FX

Contact Us

Request A Quote
Product Details
Locking:
Cable Clamp + Key Lock
Fusion Splicing Tray:
Dual-sided Tray For Fusion Splicing And Fiber Storage
Material:
ABS+PC
Color:
Gray/Black
Installation Method:
Wall-mounted Or Pole-mounted
Splitter TyaCable Entry Port Stylepe:
Snap-in Or Optional Waterproof Connector
Adapter Installation Slots:
4 Columns, 4 Layers
Function:
Fiber Distribution, Signal Splitting, And Fiber Jumpers
Payment & Shipping Terms
Minimum Order Quantity
5
Delivery Time
5-15 days
Payment Terms
T/T /Paypal/ Trade Assurance Order via Alibaba
Supply Ability
20000PCS/month
RELATED PRODUCTS
Contact Us
86-755-83570641
Contact Now
Product Description

 16 - core Fiber Distribution Box 2 in 16 out Cable Entry Ports Midspan / Gland / Dust-proof Cover Optional Quick-Open



JFFDB-216-16B-FX Fiber Distribution Box is an outdoor terminal endpoint for fiber optic cables, used to connect indoor drop cables in FTTx network systems. With a 2-input, 16-output design, it can distribute two input fiber signals to sixteen target devices or locations. This allows for splitting and distributing two fiber signals to meet the demands of multiple terminal devices.



♦ Features

①High mechanical strength. Made of PC and ABS, solid and insulated

② High IP level. Up to IP65, waterproof, dustproof

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 0

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 1

③Capacity of adapters: Max. 16 SC Simplex adapters

④Reasonable design and ample space for fiber splicing and storage, to guarantee the min. bending radius 40mm

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 2

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 3

⑤Cable entry ports: 2 gland entry ports, for 6~12mm cable, 16 output ports for 2.0*3.0mm drop cable

⑥  Accommodate splitters. one 1*16 or two 1*8 optical splitters can be installed

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 4

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 5

⑦ Mounting method: wall mounting, pole mounting (hoop clamp is requested)

-

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 6

-



Applications

1. FTTH
2. GPON
3. ODN



Dimension

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 7

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 8

XYZ axis 45° oblique view

Back view

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 9

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 10

Top view

Side view



♦ Available Accessories

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 11

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 12

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 13

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 14

Expansion screw *4 sets

Protective sleeve 55mm *16 pcs

Nylon ties *4 pcs

Bolt *2 pcs

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 15

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 16

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 17

-

Rubber piece and fixing parts for entry port *1 set

Key *2 pcs

Hoop clamp *2pcs (Optional, for pole mounting)

-



♦ Product Packaging

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 18

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 19

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 20

Pack the product into PE bags

Pack the product into inner boxes and seal the boxes

Pack multiple inner boxes into an outer box and seal the box



Factory Strength

Specialization:


JFOPT has professional production technology and equipment for Fiber Optic Splitter Distribution Boxes. Combined with extensive feedback from engineering customers, we continuously develop and mold various distribution boxes with different functions to meet diverse usage requirements.

16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 21

Manufacturing Capacity:


JFOPT uses precision injection molds and precision injection molding equipment for the production of fiber distribution boxes, and has assembly lines in place for the rapid assembly of a large number of these boxes.



16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 22

Quality Control:


JFOPT implements strict quality control, with quality inspections at various stages of production, including raw material procurement, injection molding, material cutting, and assembly.



16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 23

Standardization:


JFOPT has an experienced R&D team with expertise in structural design, mold design, and structural optimization. JFOPT can provide cost-effective overall solutions based on end customers' usage requirements to meet different needs.



16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 24

Technological Innovation:


JFOPT focuses on technological innovation and continuously upgrades and innovates our products. We have developed over 200 sets of plastic molds to meet various customer requirements.



16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 25

Service and Technical Support:


JFOPT provides comprehensive pre-sales and after-sales services, including technical consultation, product recommendations, and maintenance, to meet customer needs and ensure customer satisfaction.



16 Core FTTH Fiber Cable Box 2 In 16 Out Midspan Gland Dustproof Cover Optional 26



♦ Frequent Q&A

1.What should I consider when purchasing a fiber distribution and splitting box?
You should consider factors such as the required capacity, protection level, plastic material, and installation method.



2.Can the fiber distribution and splitting box be used directly after purchase?
The fiber distribution and splitting boxes produced by JFOPT are fully equipped with the necessary accessories and components for installation, so there is no need for additional purchases. Additionally, when purchasing our adapters and patch cords, you can achieve a complete set of equipment.



3.Can we customize the plastic material of the fiber distribution and splitting box?
Yes, customization of the plastic material is possible. However, there may be minimum order requirements. Please consult our sales service for more details.



4.What protection level can our fiber distribution and splitting box achieve?
Our fiber distribution and splitting boxes typically achieve an IP65 protection level.



5.What tools are required for the installation of our fiber distribution and splitting box at the construction site?
The installation of our fiber distribution and splitting box requires tools such as a fusion splicer, fiber stripping pliers, and fiber cleaning tools.



6.Can we choose different types of patch cords to match with the fiber distribution and splitting box?
We can provide matching solutions based on your specific requirements for different types of patch cords, ensuring compatibility with your equipment.



7.What is the lead time for delivery?
For standard production items, the lead time is typically 3 working days.
