Place of Origin:
CHINA
Brand Name:
JFOPT
Certification:
Product : CE / UL / ROHS / REACH , Company : ISO9001 / ISO14001
Model Number:
3U ODF 96F LC DX
Contact Us
3U 96 - core LC DX ODF Fiber Distribution Box with 4 Modular Trays
The 3U 96-core ODF distribution box is equipped with 4 standard 12-core integrated modules, with each module containing 12 LC DX adapters, allowing for a total fusion capacity of 24 fibers per integrated modules. When installing LC DX adapters, a set of heat shrink tube slots is added to the integrated modules. JFOPT ODF integrated modules offers optional 12-color 0.9mm tail fibers, ribbon branch pigyails, or bundle branch pigtails. The front and side of the box provide ample space for cable routing. The ODF box has cable entry and exit devices on both sides, allowing for flexible wiring options based on actual requirements. The T-shaped appearance of the box, combined with internal panel support, ensures a sturdy structure and increased mechanical strength.
♦ Product Features
|
① Integrated tray design provides ample storage space |
②Adjustable mounting holes allow for flexible installation positions based on cabinet space |
|
|
|
|
③Made of high-quality cold-rolled steel with sufficient thickness, ensuring excellent mechanical performance |
④Lower flip door panel provides protection for the front wiring area |
|
|
|
|
⑤Various interface types are available to accommodate different equipment |
- |
|
|
- |
♦ Applications
1.Data centers.
2.Backbone networks.
3.FTTZ and FTTB cabling systems.
♦ Distribution Box Size
♦ Auxiliary Material Information
|
|
|
|
|
3*100mm cable ties * 8 pieces |
Rack mounting nuts and screws * 4 sets |
Single-core heat shrink tubing * quantity based on the number of cores |
♦ Product Packaging
|
|
|
|
|
Pearl cotton protection and bubble wrap for the four corners of the distribution box |
Packed into inner boxes and sealed |
Several inner boxes packed into outer boxes and sealed, |
♦ Factory Strength
|
Expertise: JFOPT has been focusing on fiber distribution box production for over 10 years and has professional manufacturing techniques and equipment. |
|
||||
|
Manufacturing Capacity: JFOPT utilizes precision laser cutting, metal stamping, and CNC bending equipment for manufacturing. |
|
||||
|
Quality Control: JFOPT implements strict quality control measures, including quality inspections at each stage of production, from raw material procurement to stamping, bending, and painting. |
|
||||
|
Standards: JFOPT can customize and strictly adhere to production standards based on customer requirements to ensure product consistency and performance stability. |
|
||||
|
Technological Innovation: JFOPT emphasizes technological innovation and has a professional R&D team dedicated to developing advanced and user-friendly fiber distribution boxes. |
|
||||
|
Service And Technical Support: JFOPT provides comprehensive pre-sales and after-sales services, including technical consultations, product recommendations, and maintenance, to meet customer needs and ensure customer satisfaction. |
|
||||
♦ Frequent Q&A
1.When selecting a distribution box, it is important to consider the following factors?
Ensure that it meets the requirements for wiring installation, including the thickness of the sheet metal and structural strength, to ensure a visually appealing and damage-free product.You can contact us for custom production based on your samples or technical drawings, or provide us with your requirements for us to design accordingly.
2.Can we purchase patch cords to go with our distribution box?
Yes, we can provide patch cords and pigtails according to your specific requirements to meet different wiring needs.
3.What is our delivery lead time?
For standard products, the lead time is typically 2 working days. For customized products, the lead time is usually 15 working days.
