10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant

10G Fiber Optic Patch Cable

OM4 OM5 lc lc patch cord

Flame Retardant lc lc patch cord

Place of Origin:

CHINA

Brand Name:

JFOPT

Certification:

Product : CE / UL / ROHS / REACH;Company : ISO9001 / ISO14001

Model Number:

LC - LC 2.0/3.0mm DX MM OM5

Contact Us

Request A Quote
Product Details
Fiber Count:
Simplex /Duplex
Fiber Type:
OM4 / OM5
Cable Outer Diameter:
2.0 / 3.0
Cable Jacket Material:
PVC / LSZH
Flame Retardant Rating:
OFN / OFNR / OFNP
Cable Color:
Aqua / Violet / Lime Green / Customizable
Connector Type:
LC
Maximum Bandwidth:
≥3500Mhz·km
Payment & Shipping Terms
Minimum Order Quantity
1pc
Price
Quoted based on product length / model / and loss parameters
Delivery Time
1-5 days
Payment Terms
T/T / Paypal / Trade Assurance Order via Alibaba
Supply Ability
20,000 terminations per day
RELATED PRODUCTS
Contact Us
86-755-83570641
Contact Now
Product Description

10G Fiber Optic Patch Cord LC - LC OM4 OM5 Multimode Data Center Flame Retardant Patch Cord



JFOPT's OM4/OM5 LC-LC fiber optic patch cords are made with brand new high-quality components that are heat-resistant, environmentally friendly, and durable. The ceramic ferrules have minimal attenuation and can withstand over 1000 plugging and unplugging, with low interchangeability loss. These patch cords are widely used in fiber optic communication systems, fiber equipment connections, and other environments, providing stable and efficient data transmission. JFOPT typically maintains sufficient inventory with cable diameters of 1.6mm, 1.8mm, 2.0mm, and 3.0mm available, and custom lengths of up to 500 meters. Highly customized solutions are achievable with quick delivery. With large-scale cable production line and comprehensive production and quality control process, JFOPT ensures safe and prompt delivery of orders.



♦ Features

① Carrier-grade product, low loss, high bandwidth

②Made with bend-insensitive optical fibers to improve transmission stability

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 0

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 1

③ Utilizes high-quality and low-loss ceramic ferrules for minimal attenuation and high reliability

④ Excellent polihsing technology ensures accurate fiber core offset

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 2

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 3

⑤100% factory terminated and tested to guarantee transmission performance

-

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 4

-



Applications

1.Fiber access networks.
2.Fiber data transmission.
3.Fiber optic communication systems, cable television networks, telecommunication networks.
4.Local area networks (LANs), wide area networks (WANs), FTTx.



♦ Simplex cable parameters

Item

Parameters

Fiber Type

OM4 / OM5

Fiber Count

1

Strength Member

Aramid yarn

Outer Jacket Material

LSZH / PVC

Outer Jacket Diameter

1.9±0.1mmmm

2.9±0.1mm

Outer Jacket Color

Green / Violet / Lime Green / Customizable

Tensile Strength (Long-term)

60N

80N

Tensile Strength (Short-term)

100N

150N

Crush Resistance (Long-term)

100N/cm

100N/cm

Crush Resistance (Short-term)

500N/cm

500N/cm

Minimum Bending Radius (Dynamic)

50mm

60mm

Minimum Bending Radius (Static)

30mm

30mm

Operating Temperature

-20~60℃

Storage Temperature

-20~60℃

Fire Rating

OFN / OFNR / OFNP



♦ Duplex cable parameters

Item

Parameters

Fiber Type

OM4 / OM5

Fiber Count

2

Strength Member

Aramid yarn

Outer Jacket Material

LSZH / PVC

Outer Jacket Diameter

(1.9±0.1)×(3.9±0.2)mm

(2.9±0.1)×(5.9±0.2)mm

Outer Jacket Color

Green / Violet / Lime Green / Customizable

Tensile Strength (Long-term)

90N

160N

Tensile Strength (Short-term)

150N

300N

Crush Resistance (Long-term)

200N/cm

200N/cm

Crush Resistance (Short-term)

1000N/cm

1000N/cm

Minimum Bending Radius (Dynamic)

50mm

60mm

Minimum Bending Radius (Static)

30mm

30mm

Operating Temperature

-20~60℃

Storage Temperature

-20~60℃

Fire Rating

OFN / OFNR / OFNP





♦ 3D Geometric Parameters (Optional)

Items

UPC

APC

SC/FC/ST

LC

SC/FC

LC

SM

MM

SM

MM

SM

SM

Radius of curvature (mm)

10-25

7-25

5-12

Apex offset (μm)

≤50

≤30

Fiber Depressed (nm)

±100

Angle deviation (°)

0

8±0.3

Bond angle deviation (°)

0

±0.5

Fiber diameter (μm)

123-135



♦ Connector Housing Color Options

LC connector

Multimode

Beige

Aqua

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 5

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 6

Heather Violet

Lime Green

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 7

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 8



♦ Connector Options

Duplex

Cable diameter

Boot type


Drawings

2.0mm
Duplex

Standard boot

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 9

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 10

2.0mm
Duplex

Short boot 1

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 11

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 12

2.0mm
Duplex

Short boot 2

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 13

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 14

3.0mm
Duplex

Standard boot

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 15

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 16

3.0mm
Duplex

Short boot 1

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 17

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 18

3.0mm
Duplex

Standard UNIBOOT

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 19

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 20

2.0/3.0mm
Duplex

45° boot

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 21

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 22

2.0/3.0mm
Duplex

90° boot

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 23

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 24



Simplex

Cable diameter

Boot type


Drawings

2.0mm
Simplex

Standard boot

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 25

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 26

2.0mm
Simplex

Short boot 1

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 27

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 28

2.0mm
Simplex

Short boot 2

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 29

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 30

3.0mm
Simplex

Standard boot

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 31

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 32

3.0mm
Simplex

Short boot 1

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 33

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 34

2.0/3.0mm
Simplex

45° boot

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 35

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 36

2.0/3.0mm
Simplex

90° boot

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 37

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 38



♦ Duplex Polarity Selection

TYPE A-B(Straight)

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 39

TYPE A-A(Crossing)

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 40



♦ Product Packaging

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 41

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 42

Thickened ziplock bag

Thickened carton



Factory Strength

Specialization:


JFOPT has over 20 years of focus on fiber optic patch cord production and possesses professional production techniques to produce high-quality, high-performance fiber optic patch cords.

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 43

Manufacturing Capacity:


JFOPT has 5 production lines and equipment that enable fast and efficient production of a large quantity of fiber optic patch cords to meet customer demands.

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 44

Quality Control:


JFOPT implements strict quality control measures, including professional quality inspections and monitoring at every stage from raw material procurement to production processes, conducting insertion loss tests and end-face inspections to ensure product quality.

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 45

Standardization:


JFOPT can develop and strictly adhere to fiber optic patch cord production standards according to customer requirements, ensuring consistency and performance stability of the products.

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 46

Technological Innovation:


JFOPT emphasizes technological innovation and has a dedicated research and development team continuously developing advanced and high-performance fiber optic patch cords.

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 47

Service and Technical Support:


JFOPT provides comprehensive pre-sales and after-sales services, including technical consultation, product recommendations, and post-sales maintenance, to meet customer needs and ensure customer satisfaction.

10G Fiber Optic Patch Cable LC-LC OM4 OM5 Multimode Data Center Flame Retardant 48



♦ Frequent Q&A

1.When customizing fiber optic jumpers, you need to consider the following factors?
Length of the fiber optic jumper/Cable material/Fiber type and core count/Duplex polarity/Color/Labeling and customization requirements.



2.How do we ensure the stability of our fiber optic jumpers?
JFOPT's standard fiber optic jumpers undergo 100% insertion loss testing and end-face inspection. Multiple inspections are conducted to ensure stable product quality.



3.What other advantageous products do we offer besides E2000 jumpers?
In addition to E2000 jumpers, we also produce LC/FC/ST/SC and other standard model jumpers, various connector adapter jumpers, MPO adapters for standard connectors (such as LC), outdoor waterproof cables and jumpers, as well as various non-standard and special model fiber optic connectors.



4.What is our delivery time?
For standard products, our delivery time can be controlled within 2 working days, ensuring fast shipment to meet your needs.
