OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC

9.0mm Breakout Fiber Cable

Base Station Cable 2.0mm Sub Cable

SC UPC Breakout Fiber Cable

Place of Origin:

CHINA

Brand Name:

JFOPT

Certification:

Product : CE / UL / ROHS / REACH , Company : ISO9001 / ISO14001

Model Number:

SC / UPC - SC / UPC 4/6/8C FTTA Cable

Contact Us

Request A Quote
Product Details
Number Of Cores:
4/6/8
Cable Type:
Indoor Breakout / Base Station Cable (2.0mm Sub - Cable)
Cable Outer Diameter:
7.0~9.0mm
Outer Sheath Material:
PVC / LSZH / TPU / PU / Customized
Connector Type:
SC
Length:
1M/3M/5M/10M/20M/50M/100M Customized
Fiber Type:
Single Mode / Multimode
End Face:
APC / UPC
Payment & Shipping Terms
Minimum Order Quantity
1pc
Price
Price negotiable
Delivery Time
1-5 days
Payment Terms
T/T / PAYPAL / Trade Assurance Order Via Alibaba
Supply Ability
20000 terminations per day
RELATED PRODUCTS
Contact Us
86-755-83570641
Contact Now
Product Description

 2.0mm Subcable Distribution Cable Long - Distance Fiber Cable 4/6/8 Cores Outer Diameter Of 7.0-9.0 Pre Terminated Optic Cable With Sc / Upc Connectors Jumper



JFOPT can provide a variety of multi-core pre-terminated fiber optic jumpers, ranging from 2 to 288 cores, with different structures including distribution cables, trunk cables, and armored cables. Typically, these cables have a 2.0mm or 3.0mm sub-cable structure, which can withstand greater tensile forces in long-distance installations due to the high-strength aramid and inner cable jacket. The outer sheath material of the fiber optic cable can be customized to meet different fire-resistant requirements, such as LSZH (Low Smoke Zero Halogen) or TPU (Thermoplastic Polyurethane). These jumpers are widely used in base station communications and feature characteristics such as waterproofing and abrasion resistance. JFOPT usually maintains sufficient stock of multi-core fiber optic cables and has its own cable production lines equipped with high-precision cable cutting machines specifically designed for large-core cable customization, enabling fast delivery of long-length and large-volume orders.



♦ Features

① Secure and stable multi-core pre-terminated ends

② 2.0mm sub-cable with aramid yarn for enhanced mechanical performance

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 0

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 1

③ Grade A ceramic ferrules for ultra-low insertion loss

④100% factory termination and testing to ensure good performance of each channel, loss, end-face quality and appearance

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 2

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 3

⑤ Customizable cable color, length, packaging, labels, and other special requirements



OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 4

-



Applications

1.Fiber optic access networks.
2.Fiber optic data transmission.
3.Base station communications.
4.FTTA (Fiber to the Antenna).



♦ Connector Parameters

Connector Type

SC / LC / FC / ST

Ferrule Type

Single - mode : UPC / APC ; Multimode : UPC

Ferrule Material

Grade A Zirconia Ceramic

Connector Color

Blue / Green / Beige / Aqua / Purple

Insertion Loss

≤0.3dB/≤0.2dB/≤0.15dB

Return Loss

Single - mode : UPC ≥ 50dB ; APC ≥ 60dB ; Multimode : ≥ 25dB

Repeatability

≤0.2dB

Interchangeability

≤0.2dB



♦ Breakout cable parameters

Project

Parameter

Fiber type

G652D / G657A1 / G657A2 / OM1 / OM2 / OM3 / OM4 / OM5

Number of Fibers

2

4

6

8

12

Subcable Outer Diameter

2.0mm

Strength Member

Aramid yarn

Outer Jacket Material

PVC / LSZH

Central Strength Member

/

RFP

Outer Jacket Diameter

7.0mm

8.5mm

10.0mm

12.5mm

Outer Jacket Color

Yellow / Orange / Aqua / Green / Violet / Customized

Tensile Strength (Long-term)

200N

250N

300N

400N

Tensile Strength (Short-term)

400N

600N

800N

1000N

Crush Resistance (Long-term)

300N/10cm

Crush Resistance (Short-term)

1000N/10cm

Minimum Bending Radius (Dynamic)

20D

Minimum Bending Radius (Static)

10D

Operating Temperature

-20~60℃

Storage Temperature

-20~60℃

Fire Rating

OFN / OFNR / OFNP



♦ Base Station cable parameters

Project

Parameter

Fiber type

G652D / G657A1 / G657A2 / OM1 / OM2 / OM3 / OM4 / OM5

Number of Fibers

2

4

Subcable Outer Diameter

2.0mm

Strength Member

Aramid yarn

Outer Jacket Material

LSZH / Customized

Outer Jacket Diameter

7.0mm

Outer Jacket Color

Black / Customized

Tensile Strength (Long-term)

200N

Tensile Strength (Short-term)

400N

Crush Resistance (Long-term)

500N/10cm

Crush Resistance (Short-term)

1000N/10cm

Minimum Bending Radius (Dynamic)

20D

Minimum Bending Radius (Static)

10D

Operating Temperature

-20~60℃

Storage Temperature

-20~60℃

Fire Rating

OFN / OFNR / OFNP



♦ 3D Geometry Parameters (optional)

Items

UPC

APC

SC/FC/ST

LC

SC/FC

SM

MM

SM

MM

SM

Radius of curvature (mm)

10-25

7-25

5-12

Apex offset (μm)

≤50

≤30

Fiber Depressed (nm)

±100

Angle deviation (°)

0

8±0.3

Bond angle deviation (°)

0

±0.5

Fiber diameter (μm)

123-135



♦ Branching Options for Breakout Cables

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 5

Main Cable Structure

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 6

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 7

Fanout with equal length

Fanout with unequal length

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 8

Branching of direct Sub-unit



♦ Branching Options for Base Station Cables

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 9

Main Cable Structure

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 6

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 7

Fanout with equal length

Fanout with unequal length

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 12

Branching of direct Sub-unit



♦ Product Packaging

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 13

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 14

Thickened self-sealing bag packaging

Thickened carton packaging



 Factory Strength

Expertise:


With over 20 years of experience in fiber optic jumper production, JFOPT has a professional production team capable of manufacturing high-quality and high-performance fiber optic jumpers.

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 15

Manufacturing Capacity:


JFOPT has 5 production lines and equipment to quickly and efficiently produce a large quantity of fiber optic jumpers to meet customer demands.

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 16

Quality Control:


JFOPT implements strict quality control measures, including rigorous testing and monitoring of materials and production processes, such as insertion loss testing and end-face inspection, to ensure product quality.

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 17

Standards Compliance:


JFOPT can customize and strictly adhere to fiber optic jumper production standards based on customer requirements to ensure product consistency and performance stability.

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 18

Technological Innovation:


JFOPT emphasizes technological innovation and has a dedicated R&D team focused on developing advanced and high-performance fiber optic jumpers.

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 19

Service Support:


JFOPT provides comprehensive pre-sales and after-sales services, including technical consultation, product recommendations, and post-sales repairs, to meet customer needs and ensure customer satisfaction.

OD 7.0-9.0mm Breakout Fiber Cable Base Station Cable 2.0mm Sub Cable With SC/UPC 20



♦ Frequent Q&A

1.What should be considered when customizing standard fiber optic patch cords?
Total length of the patch cord / Branch length / Branch cable diameter / Fiber cable material / Fiber type and number of cores / Color / Labeling and other customization requirements.



2.How do we ensure the stability of our standard fiber optic patch cords?
JFOPT's fiber optic patch cords undergo a process design to ensure that 100% of the connectors pass the insertion loss test and end-face inspection, guaranteeing stable parameters.



3.What is our delivery lead time?
For standard products, our delivery lead time is controlled within 5 working days, ensuring quick shipment.
